CVT space warping based multi-scale neural implicit surface reconstruction for outdoor scenes

doi:10.11947/j.AGCS.2025.20240280

Abstract

Abstract:

In recent years, volumetric rendering-based 3D implicit representation methods have achieved notable success in geometry and radiance reconstruction. These methods can simultaneously reconstruct geometric structures and render photorealistic images. However, in outdoor scene reconstruction, the uneven spatial distribution of captured images often leads to suboptimal reconstruction results. To address this issue, this paper proposes a method that represents the spatial distribution of images using sampling points. Through Delaunay triangulation and a centroidal Voronoi tessellation strategy, unevenly distributed sampling points are iteratively transformed into a uniform distribution, thereby achieving uniform allocation of the implicit representation and ensuring the quality of the implicit reconstruction. Furthermore, this concept of spatial transformation of sampling points is embedded into implicit representation frameworks of different paradigms, enabling multi-scale implicit reconstruction of outdoor scenes. Experimental results on implicit 3D reconstruction of real-world outdoor scenes demonstrate that the proposed centroidal Voronoi tessellation transformation ensures the reconstruction accuracy of building structures and significantly improves the multi-scale reconstruction results of existing implicit representation methods.

Key words: photogrammetry, 3D reconstruction, neural implicit surface, centered Voronoi tessellation, novel view synthesis, volume rendering

CLC Number:

P228
